RAL1005 Epoxy Polyester Powder Coating , Woody Texture Affordable Powder Coating

Name: RAL1005 Epoxy Polyester Powder Coating Woody Texture Affordable Powder Coating
Brand: TOPO
Price: 1 USD

Quality RAL1005 Epoxy Polyester Powder Coating , Woody Texture Affordable Powder Coating wholesale

Brand Name : TOPO

Model Number : D-RAL1005

Certification : CE, BV, ROHS

Place of Origin : Ukraine

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 400 T/Month

Delivery Time : 7 days

Packaging Details : Two-ply PVC bag inside with carton box, net weight 20/25kg

Color : honey yellow

Application : Spray

Product : iron

Texture : woody

Package : 25kg

Shelf Life : 10 mos

Contact Now

RAL1005 honey yellow High Quality Competitive Price Decorative Epoxy Polyester Powder Coating

Pre-treatment
The overall quality of the coating system is largely dependent on the type and quality of the pre-treatment. The recommended types of pre-treatment for the most frequently used substrates are:

Aluminium	Chromate conversion
Steel	Zinc phosphate
Zinc coated steel	Zinc phosphate or chromate conversion

Item	Index	Note
Appearance(visual)	Homogeneous color without any agglomerate
Fineness(180 mesh sieve residue)	<0.5%	per custom’s request
Fused flowability(mm)	15°C±2°C 20-50mm(tilt test)	per custom’s request
Gel time	200±2°C 30-180s
Curing conditions	200°C/10min	Effective temperature

Application Area

1. Household Applications	7. Used for Security Door
2. Car Coating	8. Radiator & Heat Sin
3. Used for Valve	9. Corrosion Prevention of Pipes
4. Track Traffic	10. Communications Equipments
5. Aerospare field	11. Hardware & Brightwork
6. Fitness Equipment	12. Zincing & Aluminium

Item	Index
Color	In accordance with standard panels or within the range, negotiated by custom or supplier
Appearance(visual)	Smooth, slight orange peeled
Gloss(60°gauge head)	High gloss type≥85% Semi gloss type:51-84% Low gloss type:50-15% Matt type:<14%
Cured film thickness	60-80μm
Impact resistance	50kg.cm (4.9Nm) pass (direct)
Pencil hardness	2H without scratch
Adhesion(cross cut test)	1mm 6x6 0 grade
Bending test	3mm pass
Salt spray test	500h <1 grade
Humid heat resistance	500h <1 grade
Cupping test	≥6mm

RAL1005 Epoxy Polyester Powder Coating , Woody Texture Affordable Powder Coating
